Name: Bifacial 700w Solar Panel Bifacial PV Cells High Voltage
Brand: Yangtze
Price: 1 USD

Brand Name : Yangtze

Model Number : YS700M-132B

Certification : CE/TUV/ISO/ROHS/INMETRO

Place of Origin : China

MOQ : 30 pieces

Price : negotiable

Payment Terms : L/C, T/T, Western Union,Credit Card

Supply Ability : 20000 pieces/Week

Delivery Time : 7-20 days

Packaging Details : Pallet+Carton Box

Frame : Anodized Aluminium Alloy

Junction Box : IP68 Rated

Solar cell : Half Cell 10BB

Glass : 3.2mm High Transmission Low Iron Tempered Glass

Backing Color : White or Black or Transparent

OEM Order : Acceptable

Class : Grade A

Rated Power : 700W

Dimension : 2384*1303*35mm

Effciency : 21.7%

Contact Now

700W Bifacial Solar Panel High Voltage Enhanced Mechanical Load For Farm

Bifacial 700w Solar Panel Bifacial PV Cells High Voltage

Model Type	YS660M-132	YS670M-132	YS680M-132	YS690M-132	YS700M-132
Rated Maximum Power at STC	660W	670W	680W	690W	700W
Maximum Power Voltage (Vmp)	38.38V	38.68V	38.98V	39.28V	39.58V
Maximum Power Current (Imp)	17.20A	17.33A	17.45A	17.57A	17.69A
Open Circuit Voltage ( Voc)	45.55V	45.85V	46.15V	46.45V	46.75V
Short Circuit Current (Isc)	18.45A	18.54A	18.66A	18.79A	18.92A
Module Efficiency	21.1%	21.4%	21.7%	22.0%	22.3%
Working Conditions&Working Conditions
Operating Temperature		-40°c~+85°c
Maximum System Voltage		DC 1000V(IEC) / 1500V(IEC)
Maximum Series Fuse		25A
Power Tolerance		0~+5W
Temperature Coefficient of Pmax		-0.35%/°c
Temperature Coefficient of Voc		-0.29%/°c
Temperature Coefficient of Isc		+0.048%/°c
STC(Standard Testing Conditions): lrradiance 1000W/m2 , Cell Temperature 25 'C, Spectra at AMl.5
NOCT (Nominal Operating Cell Temperature): lrradiance 800W/m2 , Ambient Temperature 20 'C, Spectra at AMl.5, Wind at l m/S

Bifacial 700w Solar Panel Bifacial PV Cells High Voltage
